Ultrasonicwater meter is an innovative flow metering device that plays an important role in the field of modern water resource management.
1. Working principle
Ultrasonicwater meter measures water flow based on the propagation characteristics of ultrasound in water. An ultrasonic transducer is set inside the water meter to alternately transmit and receive ultrasonic signals. When water flows, the ultrasonic propagation speed in the downstream direction is faster than that in the upstream direction, and the difference in ultrasonic propagation time or frequency caused by the water flow speed is accurately measured. Then, based on the built-in mathematical model, combined with parameters such as the size of the pipe, these data are converted into water flow rate, and the water volume is finally calculated.
2. Product features
High-precision measurement
Not affected by water quality and water pressure fluctuations, high-precision measurement can be maintained in low and high flow conditions. For example, it can accurately measure from the trickle of daily water use by residents to the large flow of fire water.
Strong durability
Ultrasonicwater meter does not have the mechanical parts of traditional water meters, and there is no inaccurate measurement caused by mechanical wear and corrosion. The internal electronic components have been specially treated to adapt to various complex installation environments and can work stably for a long time.
Low maintenance requirements
It does not require regular cleaning of internal impellers and other components like mechanical water meters. At the same time, its fault warning function facilitates timely detection of potential problems, reducing maintenance workload and costs.
Flexible installation
It can be installed horizontally or vertically, and the requirements for the installation environment are relatively loose. Moreover, the pipe diameter has a wide range of adaptation, which can meet the metering needs of pipes of different specifications.
3. Application scope
Ultrasonicwater meter can achieve accurate household water metering in residential buildings; in commercial buildings such as office buildings, shopping malls and other places, it can accurately count water consumption; in the industrial field, it is used for water monitoring and cost accounting in the production process, providing reliable data support for the rational use and management of water resources.
