1. Product Overview
Pressure transmitter is a precision instrument that converts pressure signals into standard signals that can be transmitted. It is widely used in many fields such as industrial process control and automatic monitoring.
2. Features
High-precision measurement
Pressure transmitter uses advanced sensor technology to accurately measure pressure values. Whether it is high pressure, medium pressure or low pressure environment, its measurement accuracy can meet strict industrial requirements. It can provide reliable data in scenarios such as monitoring small pressure changes in chemical production processes or accurately controlling high pressure conditions in hydraulic systems.
Multiple pressure types are compatible
It can measure different types of pressure such as gauge pressure, absolute pressure and differential pressure. When measuring gauge pressure, it can reflect the pressure value relative to atmospheric pressure; for absolute pressure measurement, it can accurately obtain the pressure relative to absolute vacuum; in differential pressure measurement, it can accurately measure the difference between two pressure points, which is very critical in applications such as flow measurement (calculating flow by measuring the differential pressure before and after the throttling device).
Stable and reliable signal output
The Pressure transmitter converts the measured pressure signal into a standard electrical signal (such as 4 - 20mA current signal or 0 - 5V/1 - 5V voltage signal, etc.). These standard signals have strong anti-interference ability and can be stably transmitted in complex industrial electromagnetic environments, ensuring the accuracy of signal transmission to the control system for effective control and monitoring operations.
Good environmental adaptability
It can adapt to various harsh industrial environments. Whether it is high temperature, low temperature, humid or corrosive environment, it can work normally. For example, in the high temperature environment of a steel smelter or the humid and corrosive environment of a sewage treatment plant, the performance of the Pressure transmitter is still reliable.
Compact structural design
The product has a compact structure and is easy to install in various limited spaces. Whether it is installed on a pipeline, on a container wall or integrated into an automation device, it will not take up too much space and is convenient for use with other equipment.
